Temper H14 / H24 1000 Series Aluminum Round Plate 2.6mm Thick For
Traffic Warning
Quick Detal:
We manufacture and supply Aluminium Circle in Zhengzhou, Henan,
China to our customers. These are offered in various thickness,
tamper, length, width and dimensions to meet specific needs of the
clients. Best quality aluminium is used in the manufacturing
process that have define characteristics of chemical composition.
Description:
We are one of the best efficient manufacturer and supplier of an
exceptional range of Aluminium Circles. These are made using top
grade aluminium to make sure durability. We offered range is
well-known to provide maximum performance even in long run.
Manufactured using advanced technique of production, we provide an
special range of Aluminium Circles. These are highly recognized for
rust resistance which boosts the service life of our products.
The properties of aluminum circle for pots, cookware, nonstick
aluminium circle (or shaped blanks) make them ideal for use in a
number of markets including the cookware, automotive and lighting
industries etc
1. Low anisotropy, which facilitates deep drawing
2. Strong mechanical properties
3. High and homogeneous heat diffusion
4. Ability to be enameled, covered by PTFE (or others), anodized
5. Good reflectivity
6. High strength-to-weight ratio
7. Durability and resistance to corrosion
Aluminum disc Surface Finish: Bright & smooth surface, without flow
lines, slightly oiled to avoid White
rusting. Smooth, Brightly, No Zone of Fracture, No Scratched, No
oil Sludge
Our motto and mission is to offer best service for our customer
with Heart and Soul.
Chemical composition
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 1060 | 0.250 | 0.350 | 0.050 | 0.030 | 0.030.- | - | 0.050 | 0.030 | 99.6 |
| 1070 | 0.200 | 0.250 | 0.040 | 0.030 | 0.030 | - | 0.040 | 0.030 | 99.7 |
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.050 | - | - | 0.100 | - | 99.0 |
| 3003 | 0.600 | 0.700 | 0.05-0.20 | 1.0-1.5 | - | - | 0.100 | - | remains |
| 3105 | 0.600 | 0.700 | 0.300 | 0.30-0.8 | 0.20-0.8 | 0.200 | 0.400 | 0.100 | remains |
| 5052 | 0.250 | 0.400 | 0.100 | 0.100 | 2.2-2.8 | 0.15-0.35 | 0.100 | - | remains |
| 5154 | 0.250 | 0.400 | 0.100 | 0.100 | 3.1-3.9 | 0.15-0.35 | 0.200 | 0.200 | remains |
| 5754 | 0.400 | 0.400 | 0.100 | 0.500 | 2.6-3.6 | 0.300 | 0.200 | 0.150 | remains |
| 5182 | 0.200 | 0.350 | 0.150 | 0.20-0.50 | 4.0-5.0 | 0.100 | 0.250 | 0.100 | remains |
| 6061 | 0.3-0.7 | 0.500 | 0.100 | 0.030 | 0.35-0.8 | 0.030 | 0.100 | - | remains |
| 8011 | 0.5-0.9 | 0.6-1.0 | 0.100 | 0.200 | 0.050 | 0.050 | 0.100 | 0.080 | remains |
| 8079 | 0.200 | 0.300 | 1.0-1.6 | 0.100 | 0.6-1.3 | 0.100 | 0.250 | 0.100 | remains |
Product Features of cookware Aluminium circle:
a. Wide range of selection on circles' size including customized
shape and size;
b. Excellent deep drawing and spinning quality;
c. RoHS and REACH compliance.
Specification
| Specification | aluminium sheet circle |
| Alloy: 1050, 1060,1070, 1100, 1200,3003 ,6061 etc. |
| Temper: TO, H12, H22, H14, H24, H26, H18 etc. |
| Thickness: 0.2-200mm |
| Width: Up to 1800mm |
| Length: Up to 6000mm |
| Surface treatment: mill finished, anodized, embossed, PVC coated |
| Feature | Price is much more competitive than that of other series. |
| Satisfy regular industrial process of stamping, drawing with good
elongation, tensile strength and high formability. |
| Great plasticity, corrosion resistance, electrical conductiviy and
termal conductivity. |
| Easy to be welded. |
| Easy to be pressure processed, extended and bent. |
| Application | Sign board, Advertising board, Building decoration, Car body,
Cooking utensil, Lamp holder, Fan leaf, Electrical part, Chemical
instrument, Machined part, Deep-drawn or spinned part, Welded part,
Heat exchanger, Clock surface, Decotation, Reflective instrument
etc. |
| Alloy | Chemical Component %≤ |
| Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | others | Al |
| single | total |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | | | 0.05 | 0.03 | 0.03 | | 99.50 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | | | 0.05 | 0.03 | 0.03 | | 99.60 |
| 1100 | 0.95 | 0.05-0.2 | 0.05 | | | | 0.1 | | 0.05 | 0.15 | 99.00 |
| 1200 | 1.00 | 0.05 | 0.05 | | | | 0.1 | 0.05 | 0.05 | 0.15 | 99.00 |
Application of cookware Aluminium circle:
Electronics, comestic, medicine, auto parts, home appliances,
machine manfacturing, moulding, building and printing, especially
for cookware, like non-stick pan, pressure cooker, and hardware,
like lampshade, jacketing shall
FAQ
Q 1. What is the payment term of your company?
A: TT, L/C for large order; Western union, is also acceptable for
small order.
Q 2. Can you guarantee the quality is the same as that of sample
when mass production?
A: Sure. Preshipment sample can be sent, or any kind of inspection
is acceptable.
Q 3. What certificate you have?
A: SGS, CIQ or other test report can be provided if clients'
require.
Q 4. How long is the sample making time? And how can we get?
A: Within 7 days for lab making. Free sample within 1kg can be
provided on customer's international express courier.
