Pizza Trays 3003 Aluminum Disc Anti Rust 0.012" - 0.25" Thick
Diameter 19.5 Inch
Quick Detal:
Suitable for making pots, pans, pizza trays, pie pans, cake pans,
covers, kettles, basins, fryers, light reflectors and much more.
Alloys - 1050, 1060, 1070, 1100, 3002, 3003, 3004, 5052A, 5052,
5754, 6061
Hardness - O, H12, H14, H16, H18, H24
Thickness - 0.012" - 0.25"
Diameter - 3.94" - 38.5"
Surface - polished, bright, anodized
Description:
1. General Information
Circle is between 0.50 mm and 6.00mm in thickness and has a wide
variety of uses in the cookware and kitchen ware including fired
pans and pressure cooker. C.C. circle is excellent for spinning,
deep-drawing (depth less than 10 cm), color or non-sticky painting
with quite competitive price.
Hobe produces aluminum circle which meets the highest standards
while save the cost. Our strong quality control term bring you the
most-qualified products. And with state-of-the-art equipment, and
the state owned company background, we have to say, you will
understand why there are so many company choose Hobe to be their
supplier. Hobe aluminum complying with YS/T 429-2000(Chinese
Industry Standard),GB/T 3880,EN485,ASTM B209.
The main producing procedure includes the following steps:
Melting-Rolling- Cutting- Annealing--Packing
2. Technical Data
Alloy:
AA1050, AA1060, AA1070, AA1100, AA3003, AA3005, AA3105, AA5052,
AA8011
Temper:
H12, H14, H16, H18, H22, H24, H26, H32, HO, F
Thickness:
0.50-6.00mm
Diameter:
100mm- 1200mm
Standard:
GB/T3880-2006, ASTM, ISO, EU standard
Special Specification is available on customer’s requirement
Packing & shipment:
Standard wooden pallet for exporting seaworthy or according to your
requirement
Shipping: about 25 days after receipt advance
Chemical composition
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 1060 | 0.250 | 0.350 | 0.050 | 0.030 | 0.030.- | - | 0.050 | 0.030 | 99.6 |
| 1070 | 0.200 | 0.250 | 0.040 | 0.030 | 0.030 | - | 0.040 | 0.030 | 99.7 |
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.050 | - | - | 0.100 | - | 99.0 |
| 3003 | 0.600 | 0.700 | 0.05-0.20 | 1.0-1.5 | - | - | 0.100 | - | remains |
| 3105 | 0.600 | 0.700 | 0.300 | 0.30-0.8 | 0.20-0.8 | 0.200 | 0.400 | 0.100 | remains |
| 5052 | 0.250 | 0.400 | 0.100 | 0.100 | 2.2-2.8 | 0.15-0.35 | 0.100 | - | remains |
| 5154 | 0.250 | 0.400 | 0.100 | 0.100 | 3.1-3.9 | 0.15-0.35 | 0.200 | 0.200 | remains |
| 5754 | 0.400 | 0.400 | 0.100 | 0.500 | 2.6-3.6 | 0.300 | 0.200 | 0.150 | remains |
| 5182 | 0.200 | 0.350 | 0.150 | 0.20-0.50 | 4.0-5.0 | 0.100 | 0.250 | 0.100 | remains |
| 6061 | 0.3-0.7 | 0.500 | 0.100 | 0.030 | 0.35-0.8 | 0.030 | 0.100 | - | remains |
| 8011 | 0.5-0.9 | 0.6-1.0 | 0.100 | 0.200 | 0.050 | 0.050 | 0.100 | 0.080 | remains |
| 8079 | 0.200 | 0.300 | 1.0-1.6 | 0.100 | 0.6-1.3 | 0.100 | 0.250 | 0.100 | remains |
Product Features of cookware Aluminium circle:
a. Wide range of selection on circles' size including customized
shape and size;
b. Excellent deep drawing and spinning quality;
c. RoHS and REACH compliance.
Manufacturing of cookware Aluminium circle:
Aluminium sheet - Punch - Aluminium Circles
Specification
| Specification | aluminium sheet circle |
| Alloy: 1050, 1060,1070, 1100, 1200,3003 ,6061 etc. |
| Temper: T6 O, H12, H22, H14, H24, H26, H18 etc. |
| Thickness: 0.2-200mm |
| Width: Up to 1800mm |
| Length: Up to 6000mm |
| Surface treatment: mill finished, anodized, embossed, PVC coated |
| Feature | Price is much more competitive than that of other series. |
| Satisfy regular industrial process of stamping, drawing with good
elongation, tensile strength and high formability. |
| Great plasticity, corrosion resistance, electrical conductiviy and
termal conductivity. |
| Easy to be welded. |
| Easy to be pressure processed, extended and bent. |
| Application | Sign board, Advertising board, Building decoration, Car body,
Cooking utensil, Lamp holder, Fan leaf, Electrical part, Chemical
instrument, Machined part, Deep-drawn or spinned part, Welded part,
Heat exchanger, Clock surface, Decotation, Reflective instrument
etc. |
| Alloy | Chemical Component %≤ |
| Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | others | Al |
| single | total |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | | | 0.05 | 0.03 | 0.03 | | 99.50 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | | | 0.05 | 0.03 | 0.03 | | 99.60 |
| 1100 | 0.95 | 0.05-0.2 | 0.05 | | | | 0.1 | | 0.05 | 0.15 | 99.00 |
| 1200 | 1.00 | 0.05 | 0.05 | | | | 0.1 | 0.05 | 0.05 | 0.15 | 99.00 |
Application of cookware Aluminium circle:
aluminium circle for pot making,
aluminium disk for pot,
Deep drawing cookware,
spinning cookware
aluminium circle,
pot circle,
cooking utensils,
cooker, pan,pot,boiler,
cookware making
road sign and traffic sign, and signal plate
Competitive Advantage:
1. Factory direct sells, with competitive price.
2. Quick delivery time, according to the clinet's demand
3. Expert in producing cold rolled and hot rolled aluminium circles
4. Can supply small trial orders
5. Many years producing technology to supply high quality products
6. Quick reply on the customer's questions
