Utensil Deep Spinning Aluminum Disc Blank , Annealed 1050 3003
Blank Aluminum Discs
Quick Detal:
| Product name | Alumimun Disk Blank |
| Material | 1050, 3003 and Etc |
| Tempers | O, H14, H22, H24, H18 and Etc |
| Application | cookware, road sign and etc |
| Standard | China Nation Standard GB 3880-2006, ASTM, EN |
Description:
Aluminum circles is widely used in electronics, comestic, medicine,
auto parts, home appliances, machine manfacturing, moulding,
building and printing, especially for cookware, like non-stick pan,
pressure cooker, and hardware, like lampshade, jacketing shall.
Aluminum circle disc is the most widely used deep drawing products
of aluminum alloy strip.
1. Alloy: 1050, 3003, 8011
2. Temper: O,H12,H14,H16,H18,H19,H22,H24,H26
3. Hardness: 26 ~ 29
4. Elongation Percentage: 36% ~ 45%
5. Surface Treatment: Coated or Non-Coated
6. Thickness: 0.50mm ~ 6mm
7. Diameter: 100mm - 1520mm
8. Type: Discs, Circle
Packing & shipment:
Standard wooden pallet for exporting seaworthy or according to your
requirement
Shipping: about 25 days after receipt advance
Chemical composition
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 1060 | 0.250 | 0.350 | 0.050 | 0.030 | 0.030.- | - | 0.050 | 0.030 | 99.6 |
| 1070 | 0.200 | 0.250 | 0.040 | 0.030 | 0.030 | - | 0.040 | 0.030 | 99.7 |
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.050 | - | - | 0.100 | - | 99.0 |
| 3003 | 0.600 | 0.700 | 0.05-0.20 | 1.0-1.5 | - | - | 0.100 | - | remains |
| 3105 | 0.600 | 0.700 | 0.300 | 0.30-0.8 | 0.20-0.8 | 0.200 | 0.400 | 0.100 | remains |
| 5052 | 0.250 | 0.400 | 0.100 | 0.100 | 2.2-2.8 | 0.15-0.35 | 0.100 | - | remains |
| 5154 | 0.250 | 0.400 | 0.100 | 0.100 | 3.1-3.9 | 0.15-0.35 | 0.200 | 0.200 | remains |
| 5754 | 0.400 | 0.400 | 0.100 | 0.500 | 2.6-3.6 | 0.300 | 0.200 | 0.150 | remains |
| 5182 | 0.200 | 0.350 | 0.150 | 0.20-0.50 | 4.0-5.0 | 0.100 | 0.250 | 0.100 | remains |
| 6061 | 0.3-0.7 | 0.500 | 0.100 | 0.030 | 0.35-0.8 | 0.030 | 0.100 | - | remains |
| 8011 | 0.5-0.9 | 0.6-1.0 | 0.100 | 0.200 | 0.050 | 0.050 | 0.100 | 0.080 | remains |
| 8079 | 0.200 | 0.300 | 1.0-1.6 | 0.100 | 0.6-1.3 | 0.100 | 0.250 | 0.100 | remains |
Product Features of cookware Aluminium circle:
a. Wide range of selection on circles' size including customized
shape and size;
b. Excellent deep drawing and spinning quality;
c. RoHS and REACH compliance.
Manufacturing of cookware Aluminium circle:
Aluminium sheet - Punch - Aluminium Circles
Specification
| pecification | aluminium sheet circle |
| Alloy: 1050, 1060,1070, 1100, 1200,3003 ,6061 etc. |
| Temper: T6 O, H12, H22, H14, H24, H26, H18 etc. |
| Thickness: 0.2-200mm |
| Width: Up to 1800mm |
| Length: Up to 6000mm |
| Surface treatment: mill finished, anodized, embossed, PVC coated |
| Feature | Price is much more competitive than that of other series. |
| Satisfy regular industrial process of stamping, drawing with good
elongation, tensile strength and high formability. |
| Great plasticity, corrosion resistance, electrical conductiviy and
termal conductivity. |
| Easy to be welded. |
| Easy to be pressure processed, extended and bent. |
| Application | Sign board, Advertising board, Building decoration, Car body,
Cooking utensil, Lamp holder, Fan leaf, Electrical part, Chemical
instrument, Machined part, Deep-drawn or spinned part, Welded part,
Heat exchanger, Clock surface, Decotation, Reflective instrument
etc. |
| Alloy | Chemical Component %≤ |
| Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | others | Al |
| single | total |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | | | 0.05 | 0.03 | 0.03 | | 99.50 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | | | 0.05 | 0.03 | 0.03 | | 99.60 |
| 1100 | 0.95 | 0.05-0.2 | 0.05 | | | | 0.1 | | 0.05 | 0.15 | 99.00 |
| 1200 | 1.00 | 0.05 | 0.05 | | | | 0.1 | 0.05 | 0.05 | 0.15 | 99.00 |
Application of cookware Aluminium circle:
Regulatory signs
Warning signs
Guide signs
Street signs
Route markersigns
Expresswaysigns
Freewaysigns
Welcome Signs
Informational signs
Recreation and cultural interest signs
Emergency management(civil defense) signs
Temporary traffic control (construction or work zone) signs
Schoolsigns
Railroad and light rail signs
Bicycle signs
We offer a full package for the international traffic sign market:
our aluminium disc products can be delivered either as coil, sheet
or blank forms.
Competitive Advantage:
1. Factory direct sells, with competitive price.
2. Quick delivery time, according to the clinet's demand
3. Expert in producing cold rolled and hot rolled aluminium circles
4. Can supply small trial orders
5. Many years producing technology to supply high quality products
6. Quick reply on the customer's questions
